Who can identify this piece?

Discussion in 'E9 General Discussion' started by Tony.dreamer, Jul 15, 2017.

  1. eriknetherlands

    eriknetherlands Active Member

    Messages:
    287
    Likes Received:
    29
    Trophy Points:
    28
    Location:
    Netherlands, Eindhoven area
    , I did dig into this as well, as I was, and still am, plagued with an obsession for originality.

    The W&N rear floor plans are much better compared to the front one.
    I have noticed the following for the rears:
    - rear floor pans have the larger rectanular depression, it is about 10 mm to short front to back.
    - rear floor pans have the 3 beads running front to back, their distance to each other is 1 ~ 2 mm's off compared to the E9 floor to which it has to line up with.
    - and ofcourse the twist lock cap is integrated and not a seperate part anymore, (but i don't mind, as i consider this an improvement. )

    Regarding the Front floor from W&N, it is missing (see attached picture where it shows the W&N panel with modifications) :
    - the 90 degree fold, where it connects to the inner sill
    - the 5 depressions running front to back
    - the curve at the front of the footwell, where it meets the firewall
    - an 8-10 cm long bead, in the above curve, in the right front corner of the passenger footwell;
    - the rectangular depression & opening above the frame rails
    - the circular depression & opening above the frame rails
    - and the -as per Original topic- circular feature that is above identified as allegedly a ground plate for an antenna to detect loads of BS....

    The polish examples, , look better in replicating these details. I cannot comment on their exactness as i haven't seen nor measured them.
    On one point they are also missing some details, and that is that at the rear floor, the beads dont run into the large depression. they stop just before the edge, and start again in the 10 mm lower plane. they should run continuesly. (see picture with the blue Pelny panel)
    Big advantage is that with the Pelny panels, there is one less long weld to make and dress compared to the W&N panels where 2 have to be joined. For a body shop that is almost cost neutral.

    Hope this is helpful,
    Erik.


    Attached Files:

    Last edited: Jul 17, 2017 at 8:24 AM
    Tony.dreamer likes this.
  2. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    No wonder I never have seen them before. The only E9 I have ever removed the insulation from inside is the one I am restoring now which all of the floor pans were completely gone, with no evidence of the oval pieces that I can recall.....
    I love it almost every time I come back to the forum I learn something new.... it makes it so much more fun. If we were all together in a bar, I would have bought a round !!!
    Cheers!

  3. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    Thanks Eric!
    I appreciate the detailed description!
    We found the rear pans from W&N very nice at first but you are absolutely right in that the beads are few millimeter off as the floor rolls up toward the back to meet up with the bead for the section under the rear seats. This issue is worse for the right side piece it seemed to us, or at least in our case ....
    The picture above shows the slight difference. However we slit the center of the bead and then build up the weld around it and then ground it off and once dressed it up we could hardly see it...
    By the way, Kyle , in the photo does all my sensitive welding. He is exceptional in his work.

    Last edited: Jul 17, 2017 at 5:37 AM
  4. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    IMG_1626.JPG IMG_1627.JPG IMG_1628.JPG Photos of the Die

  5. eriknetherlands

    eriknetherlands Active Member

    Messages:
    287
    Likes Received:
    29
    Trophy Points:
    28
    Location:
    Netherlands, Eindhoven area
    OK Tony, you win the prize for the best tooling made! I just fabbed things with a simple router....

    more pics from the underside (of your cars that is) please.... Looks like serious work going on; for instance your frame rails are Missing In Action....!


    Attached Files:

  6. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    You noticed that ;) !!!! You should be very pleased to see what we did for the frame rails...
    The one on the car could have been patched . But it would have taken several patches and we figured it will not be structurally right. So we cut it back as far as we felt there is solid steel. I will post a photo of how we build two rails since the used one available for sale were not much better.... and new ones not available any longer.
    Let me look for the photos and I will post them..

    Last edited: Jul 17, 2017 at 10:18 PM
    mulberryworks likes this.
  7. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    IMG_0849.JPG IMG_0850.JPG
    What do you think Eric?

  8. Peter Coomaraswamy

    Peter Coomaraswamy Well-Known Member Site Donor $

    View My Garage
    Messages:
    2,780
    Likes Received:
    132
    Trophy Points:
    63
    Location:
    Austin, TX
    I see a female butterfly with the face of Jack-o-lantern wearing disheveled clothing leaning against a lamp-post at Hollywood & Vine.

    -Oh, there's an e9 in the background

  9. eriknetherlands

    eriknetherlands Active Member

    Messages:
    287
    Likes Received:
    29
    Trophy Points:
    28
    Location:
    Netherlands, Eindhoven area
    Tony, that's quite the excercise, made it all new? Just needs two drain holes to finish it off.
    I think i claimed the cleanest frame rails half a year ago, but I see that it now fully belongs in your garage!

    Did you go for OEM thickness , or did you increase it ?
    A bit thicker could help to avoid those bite marks left when lifting the car by the frame rails.
    Erik.

  10. autowerks

    autowerks Member

    Messages:
    264
    Likes Received:
    22
    Trophy Points:
    18
    Location:
    Dallas, Texas
    When I get ready to do the rusty metal wheel arch parts on my car I will buy Tony's fabricated parts if he makes them

  11. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    Erick, we did go slightly thicker. However we made sure at the the weld line connecting the old and new have very even thickness on the old part and flush weld it on the outside (exposed side so that we can grind it off even whereas we old and new fabricated pieces are not noticeable. It looked amazing. I have to get the car on a lift and take few pictures for you. Kyle, is an amazing welder. It is so much fun to watch him work on metal.

  12. Tony.dreamer

    Tony.dreamer Member Site Donor

    Messages:
    188
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Edmond , Oklahoma
    IMG_0761.JPG IMG_0761.JPG Let me try to put one of the videos...
    :rolleyes: We will see how far I can go... joe you will get especial discount!!!

  13. autowerks

    autowerks Member

    Messages:
    264
    Likes Received:
    22
    Trophy Points:
    18
    Location:
    Dallas, Texas
    Thank you my friend, you probably have to do the work too since I do not have the equipment anymore!
