central console reconstruction

Discussion in 'E9 Projects and Restorations' started by deQuincey, Mar 21, 2015.

  1. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    these cars are so easy to fix, simple materials, Wood, metal, leather,...

    got this central gear shift console from ebay

    [​IMG]

    just remove nails, and peel off the covering

    [​IMG]

    the problem is that bits from the Wood came off too, a pity, wood was partially dissintegrating, so i ahd some of the shapes with really big dents, a challenge, cos if you do not redefine the shapes the upper leather layer will show all the imperfections

    [​IMG]

    so i had to redo the Wood, using wood mastick in excess and then a file and sand paper to redefine all tiny details

    [​IMG]

    [​IMG]


    it has been a long time, recovering all the bits, including chroming, anodizing,...i chromed the steel supports and the all round plate that fix the gearshift boot, i reanodized the upper aluminium trim plates, extremely delicate pieces, if you break a support, you must find another one,...

    [​IMG]

    leather and a new plastic zip almost the same as original

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    Last edited: Mar 22, 2015
  2. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    do not forget the supports

    [​IMG]

    [​IMG]

    [​IMG]

    add a new decal

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]


    ready

  3. vraned

    vraned Member Site Donor $

    Messages:
    232
    Likes Received:
    0
    Trophy Points:
    16
    Location:
    San Jose, CA
    Beautiful work, as usual.

  4. loloe13

    loloe13 Member

    Messages:
    381
    Likes Received:
    0
    Trophy Points:
    16
    Location:
    Melbourne, Australia
    very nice DeQ, as usual.

  5. EggUK

    EggUK New Member

    Messages:
    48
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Essex, UK
    Excellent job. How did you get the material/vinyl to follow the contours of the wood frame so very well ? I see no bunching or folds as I would expect if I had attempted such a job.

    Really very nice.

  6. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    material is leather of the best quality, thus pretty thick, i used impact glue, is impossible to take pictures of the process or the work will be ruined

    using a nylon and small wood sticks to define shapes and sharp contours

  7. bfeng

    bfeng Well-Known Member Site Donor

    Messages:
    1,802
    Likes Received:
    360
    Trophy Points:
    83
    Location:
    Massachusetts, metrowest
    Your work looks better than 9/10 restoration shops I know of in New England.
    Imagine what this would cost if you paid $75/hour! Great work and a great inspiration to us shade tree folk.

  8. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    a rough estimate, i would say...

    100 euro the console core w/shipping
    1/2 hour to dissasemble
    2 hours to repair the wood
    1/2 hour to cut the leather and sew the boot
    1/2 hour to sand finish the aluminium trims
    30 eur to chrome/ anodize the metal parts
    5 eur the decal
    1,5 hours to glue the leather
    1 hour to finish assemble

    135 euro plus 6 hours @60 eur (360) = 495 eur

    no, i can not pay such a big ammount of money i prefer to make it by myself

  9. rsporsche

    rsporsche Well-Known Member Site Donor $$

    Messages:
    7,330
    Likes Received:
    992
    Trophy Points:
    113
    Location:
    Atlanta, GA
    extremely nice work deQ! this is the way that BMW should have done it originally. thank you for chronicling this process. we all have something to live up to.

    i have been looking into the same thing - doing research with finding the right black leather - that is thin enough and the right color / finish (sheen / texture). these things vary greatly.

  10. bfeng

    bfeng Well-Known Member Site Donor

    Messages:
    1,802
    Likes Received:
    360
    Trophy Points:
    83
    Location:
    Massachusetts, metrowest
    Can I send you my center console and a check for 495euro?

    John

  11. Ohmess

    Ohmess I wanna DRIVE! Site Donor

    Messages:
    2,473
    Likes Received:
    437
    Trophy Points:
    83
    Location:
    Vienna, VA
    Did you do the anodizing of the aluminum parts yourself or pay someone to do it for you?

  12. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    i have them anodized in a industrial profi shop, but i cleaned and smooth the surface first

  13. Arde

    Arde Well-Known Member

    Messages:
    3,060
    Likes Received:
    307
    Trophy Points:
    83
    Location:
    Cupertino, CA
    Can you make me one? I messed up mine when I asked a friend to help me do the auto to manual cutout. No decal please, the rest is perfect.

  14. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    i cant "make" one from scratch, i need a core, but otherwise is doable

  15. Wally Siswadji

    Wally Siswadji Member

    View My Showcase
    Messages:
    60
    Likes Received:
    8
    Trophy Points:
    8
    Location:
    Perth, Australia
    Very well done DQ.
    Did you ever restore console side panels as well, I'm really curious how to...

  16. deQuincey

    deQuincey Well-Known Member

    View My Showcase
    Messages:
    5,822
    Likes Received:
    525
    Trophy Points:
    113
    Location:
    bilbao
    Last edited: Mar 24, 2015
  17. Wally Siswadji

    Wally Siswadji Member

    View My Showcase
    Messages:
    60
    Likes Received:
    8
    Trophy Points:
    8
    Location:
    Perth, Australia
    Yes, that's the one
    Thanks DQ

  18. Wally Siswadji

    Wally Siswadji Member

    View My Showcase
    Messages:
    60
    Likes Received:
    8
    Trophy Points:
    8
    Location:
    Perth, Australia
    Yes, that's the one
    Thanks DQ

  19. bmwmadman

    bmwmadman Member

    Messages:
    529
    Likes Received:
    4
    Trophy Points:
    18
    Location:
    Escondido, CA (near San Diego)
    nice work - very well done.

  20. laldog

    laldog Member

    Messages:
    146
    Likes Received:
    0
    Trophy Points:
    16
    Location:
    Boston, MA
    wiper speed switch

    I'm wondering how the wiper speed switch is removed?

    I'm tempted to pry it out, but I'm also thinking the round plate (disk) will spin off, but I see no evidence of threads

    Option 3 may be to give the shaft a whack but that seems too simplistic.

    Do you remember how to get it out??

    Thanks in advance
