assembly sequence for the center console and lower dash pad?

[Markos]

SOMEONE MADE THAT AS ITS NOT OEM
must support a special radio as thats where it is on the face
as most radio back mounts are a bolt in the center

I can’t confirm that it isn’t OEM, but it is purpose built for the coupe and definitely not a DIY bracket. Take a closer look at what is going on with the bracket, the precision of the bends, the depression, and the alignment with factory bolt holes. It took serious equipment to make, and it is plated post fabrication.

Sadly there are very few pictures of factory radio setups. The blue book has nothing on factory radio installs on an AC car.



[aearch]

SIMPLE THE ONLY REASON THAT CENTER BRACKET IS THERE WOULD BE TO HOLD THE BACK OF THE RADIO
RADIOS HAVE A BOLT CENTERED IN THE BACK TO MOUNT TO WHATEVER IS THERE ON ANY CAR
AND YOU ADD ANUT TO KEEP THE RADIO FROM PULLING OUT.
HERES THE BRACKET IN THE BACK



[mark99]

Hi Alan,
Thanks for this photo!
Do you have any others with the radio out?, showing the AC unit, drain hose etc.?
Thanks
