Lan-Trim front grilles, lights, indicators

[deQuincey]

front grilles, lights, indicators, renew all

as winter shows his abilities, wind, water, and cold, coupe hibernates

so, it is time for the to-do list

front area needs some care,

using FLUID FILM:



[deQuincey]

indicators

reflecting part was broken in left side, so using a couple of fresh parts and some rivets:



[deQuincey]

ground conection was broken too

rivets are effective and clean



[deQuincey]

right side

new rubbers

and now they will await the rest of the work



[tmason]

I sure hope your car is an Auto going to a 5spd soon?Great job again. Tim



[Stan]

nicely done!



[rsporsche]

de Quincey, once again, you have shown us the way to make our cars better.



[deQuincey]

headlamp supports

dirty and a little rust

some months ago i bought a second hand ones from a scrapyard:

and i started preparing them for renewal, sand blasting

and these are the renewed ones, first galvanised and then epoxi painted in black

galvanised cupoles

connectors and rubber cleaned

chromed rings too

springs and little rubbers

first dissasemble of actual headlamps

start assembly ;

compare:



[Stevehose]

Nice-ready for the rain! :lol:



[rsporsche]

i bought a NOS passenger side headlight unit this summer, and i also have an extremely good drivers side. i guess now i'll take the good one and follow DQ's advice.



[deQuincey]

special procedure to clean the interior of the lamp glass, using special powders, dry cleaning and no residuals, see that the glass is blurred

shake it up,...e voila !



[HB Chris]

What headlamps are you using, the inner has three contacts, is it an H4 instead of H1 high beam?



[deQuincey]

What headlamps are you using, the inner has three contacts, is it an H4 instead of H1 high beam?

they are normal standard headlamps

the three contact is due to: low beam + position lamp + ground

high beam + ground in the other lamp makes only two contacts

regards



[CRJ Driver]

Damn..Your posts always make me feel so lazy.



[SicilianE9]

special procedure to clean the interior of the lamp glass, using special powders, dry cleaning and no residuals, see that the glass is blurred

Hold on! Wait a minute! did i miss a chapter? What are those magical special powders?



[Stevehose]

I swirled rubbing alcohol inside mine and it made a huge difference



[deQuincey]

special procedure to clean the interior of the lamp glass, using special powders, dry cleaning and no residuals, see that the glass is blurred

Hold on! Wait a minute! did i miss a chapter? What are those magical special powders?

they are glass fiber powders, used in sand blsting equipment



[deQuincey]

comming to an end

new (old) front grilles, from BLUMAX !!!! i bought them from Murray one year ago



[deQuincey]

side markers



[deQuincey]

headlamps and grilles

.

.

.
